Create and position simple geometries, text and codes with just a click of the mouse.Choice of different elements for creating marking content.Automatic segmentation for marking around perimeters and on flat surfaces, in combination with the axis of rotation and linear axesĬreate entire layouts using our user-friendly GUI.Ability to control the digital I/Os inside the laser.Parameter test module for all ACI lasers.Automatic identification and parameter setting for all connected ACI lasers (UV, green, YAG, fibre and CO2, as well as workstations).Integrated logging of program and error messages.Ability to control motor-driven axes (X-, Y- and Z-axes and axis of rotation).Ability to mark multiple elements in a matrix.Plugin interface for adding extra functions.Ability to import pixel-based files (BMP, JPG, GIF, PNG, etc.).Ability to import vector-based files (HPGL, DWG, DXF – with level differentiation).Use of all TrueType fonts installed on your Windows PC plus additional single-line fonts.Modifiers for moving, resizing, rotating and mirroring objects and marking circles fill, wobble and path modifiers.Elements for drawing lines, rectangles and ellipses.Mode elements for marking on flat surfaces, marking around perimeters, automatic segmentation, and marking pallets.Clearly laid out graphical user interface with five sections (laser and workstation status, graphics tree, elements and modifiers, preview, properties).Alongside comprehensive graphics functions, Magic Mark includes a Visual Basic programming module that makes integration into production lines easier for our customers.
Magic maps gmbh manual#
This user-friendly software includes all the functions necessary for working with both manual workstations and integration solutions.
The modern software architecture of the Magic Mark marking software enables selective access to all available functions and allows users to control the laser and laser peripherals.
